Raymarine RMK-10 Remote Keypad is an ultra-compact wired keypad accessory that provides full control of aSeries, cSeries, eSeries, eS Series and gS Series Multifunction Displays (MFDs) from any mounting location.

Features:

- The fully backlit RMK-10 includes dedicated keys for home, menu, zoom in/out, window control, waypoint management, power/brightness, as well as Evolution autopilot control
- RMK-10 also features the same multifunction rotary controller with the integrated cursor pad found on eS Series multifunction displays
- The RMK-10 can be surface-mounted or flush-mounted, and is available with key mats for horizontal or vertical installation. This gives you the flexibility to install the RMK-10 just about anywhere

RMK-10 Mounting Options:

- The RMK-10 is the perfect solution for controlling MFDs mounted beyond arms reach, or in overhead electronics boxes. Instead of reaching for the MFD, the RMK-10 brings the systems controls to you
- For the ultimate in convenience, mount the RMK-10 in the arm of your favorite helm chair. Now its easy to sit back, relax and enjoy the ride on autopilot, while still being able to interact with your navigation system
- RMK-10 is also great for bringing remote system control to secondary monitors and onboard LCD TV sets connected to the VGA or HDMI output of select e-Series, eS-Series and gS-Series displays. Now you can see and control your Raymarine navigation system from a below-deck navigation table, salon or stateroom

Utilising Raymarines RayNet high speed networking, the RMK-10 can be setup to control a single multifunction display, or multiple displays mounted at the same location. When controlling multiple displays on the same helm, the RMK-10 provides seamless control across all of the displays.

When used with aSeries or gS Series Multitouch displays, the RMK-10 brings full HybridTouch control capability to these products. The RMK-10 integrates seamlessly with the LightHouse II user interface and allows the navigation system to be operated solely by touch, by keypad, or any variation between.

Specifications:

Power:

- PoE Class: Class 1
- Nominal Supply Voltage: 12 / 24 V dc
- Operating Voltage Range: 10.8V dc to 31.2V dc
- Power Consumption: 3.84W

Environmental:

- Operating Temperature: -13F to 131F
- Storage Temperature: -22F to 158F
- Relative Humidity: Maximum 75%
- Waterproof Rating: IPX6

Wired Connections:

- Network/Power: 1 x RayNet Connector | (gS Series - 1000 Mb/s plus PoE) | (aSeries , cSeries, eSeries - 100 Mb/s)
- Alternate Power: 1 x Power Connector
